- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com.au
- Brand Name
- APC by Schneider Electric
- Product Line
- Easy Switched Rack
- Packaged Quantity
- 1 / Pack
- Product Type
- PDU
- Warranty
- Limited Warranty
- 2 Year
- Additional Warranty Information
2 Years repair and Replace
- Technical Information
- PDU Type
- Switched with Metered-by-Outlet
- Phase
- Single Phase
- Plug/Connector Type
- IEC 60309 (2P+E) 32A
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Receptacle Detail
- 20 x IEC 60320 C13
- 4 x IEC 60320 C19
- Power Description
- Input Voltage
- 230 V AC
- Input Voltage Range
- 200 V AC - 240 V AC
- Output Voltage
- 230 V AC
- Power Rating (VA)
- 7.36 kVA
- Power Rating (Watt)
- 7.40 kW
- Input Current
- 32 A
- Input Frequency
- 60 Hz
- Management
- Management
SNMP
- Remote Outlet Switching
- Yes
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Mounting Orientation
- Vertical
- Mount Type
- Rack-mountable
- Rack Height
- 0U
- Cord Length
- 3 m
- Height
- 1800 mm
- Width
- 55 mm
- Depth
- 56 mm
- Weight (Approximate)
- 7.42 kg
- Environmental Conditions
- Minimum Operating Temperature
- -5°C
- Maximum Operating Temperature
- 50°C
- Minimum Operating Humidity
- 5%
- Maximum Operating Humidity
- 95%
- Minimum Storage Temperature
- -25°C
- Maximum Storage Temperature
- 65°C
- Miscellaneous
- Package Contents
- Easy Switched Rack 24-Outlets PDU
- Installation Guide
- Certifications & Standards
CE
- Environmentally Friendly
- Yes
- Environmental Compliance
- Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
- Restriction of Hazardous Substances (RoHS)
