The TH-3070-UF is the ideal wall mounting solution for large screen displays weighing up to 200lb. The mount holds a wide variety of screens thanks to its universal mounting hole pattern that fits to most VESA and non-VESA screens. Installation is simple and quick, with the option of a theft resistant security bar for added protection. Even after installation, screen height is easily adjusted.
- General Information
- Manufacturer
- Atdec Pty Ltd
- Manufacturer Website Address
- http://www.atdec.com.au
- Brand Name
- Atdec
- Product Type
- Wall Mount
- Warranty
- Limited Warranty
- 10 Year
- Product Information
- Device Supported
- Flat Panel Display
- Number of Displays Supported
- 1
- Maximum Load Capacity
- 90.72 kg
- Minimum Screen Size Supported
- 106.7 cm
- Maximum Screen Size Supported
- 203.2 cm (80")
- Maximum Adjustable Height
- 50 cm
- Maximum Adjustable Width
- 80 cm
- Features
- Heavy Duty
- Anti-theft
- Pre-drilled Mounting Hole
- Mount Pattern
- Universal
- Mount Profile
- Low Profile
- Height Adjustable
- Yes
- Physical Characteristics
- Product Color
- Silver
- Black
- VESA Mount Compatible
- Yes
- Mounting Pattern
- 200 x 200
- 200 x 100
- 300 x 200
- 300 x 300
- 400 x 300
- 400 x 400
- 600 x 400
- 800 x 200
- 800 x 400
- Product Material
- Steel
- Height
- 53.5 cm
- Width
- 84.5 cm
- Depth
- 3.4 cm
- Miscellaneous
- Package Contents
- Fasteners
- 4 x 20mm Spacer Bush
- 4 x 13mm Spacer Bush
- 4 x Multi Washer
- 4 x Washer
- 6 x Dry Wall Anchor
- 4 x Masonry Wall Plug
- 4 x Coach Screw
- Security Bracket
- 2 x Display Bracket
- Wall Plate
- 4 x (M8x15mm) Cross Recessed Screws
- 4 x (M8x35mm) Cross Recessed Screws
- 4 x (M8x45mm) Cross Recessed Screws
- 4 x (M6x15mm) Cross Recessed Screws
- 4 x (M6x35mm) Cross Recessed Screws
- 4 x (M6x45mm) Cross Recessed Screws
- 4 x (M5x15mm) Cross Recessed Screws
- 4 x (M5x35mm) Cross Recessed Screws
- 4 x (M5x45mm) Cross Recessed Screws
- 4 x (M4x15mm) Cross Recessed Screws
- 4 x (M4x35mm) Cross Recessed Screws
- 4 x (M4x45mm) Cross Recessed Screws
- Application/Usage
- Wall
- Additional Information
- Theft resistant design (requires 2 small padlocks)
- Supports displays from 32" (81cm) to 65" (165cm)
- Distance from wall to rear of display is 1 3/4" (34mm)
- Compatibility
- LCD
- LED
- Plasma
- Assembly Required
- Yes
