- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com.au
- Brand Name
- TP-Link
- Product Type
- Transceiver/Media Converter
The MC200CM is a media converter designed to convert 1000BASE-FX fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-FX standards, the MC200CM is designed for use with multi-mode fiber cable utilizing the SC-Type connector. It works at 850nm on both transmitting and receiving data.
- Interfaces/Ports
- Total Number of Ports
- 2
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 1
- Number of SC Ports
- 1
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Fiber Mode Supported
- Multi-mode
- Fiber Optic Cable Wavelength
- 850 nm
- Maximum Distance Supported
- 550 m
- Fiber Optic Cable Core/Cladding Specification
- 50/125 µm
- 62.5/125 µm
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 1000Base-T
- 1000Base-FX
- Power Description
- Power Source
- AC Adapter
- Physical Characteristics
- Form Factor
- External
- Height
- 27.9 mm
- Width
- 94 mm
- Depth
- 73.7 mm
- Miscellaneous
- Additional Information
- Wavelength: 850 nm
- Provides switch configuration of Force /Auto transfer mode for FX port
